MBBR Filter Media Manufacturers For Wastewater Treatment Plant
MBBR technology employs thousands of polyethylene biofilm carriers
operating in mixed
motion within an aerated wastewater treatment basin. Each
individual biocarrier increases
productivity through providing protected surface area to support
the growth of heterotrophic
and autotrophic bacteria within its cells. It is this high-density
population of bacteria that
achieves high-rate biodegradation within the system, while also
offering process reliability
and ease of operation.
Technical Parameters
| Model | | PE01 | PE02 | PE03 | PE04 | PE05 | PE06 |
| Spec | mm | Φ12*9 | Φ11*7 | Φ10*7 | Φ16*10 | Φ25*12 | Φ25*12 |
| Hole Numbers | PCS | 4 | 4 | 5 | 6 | 19 | 19 |
| Efficient surface | M2/m3 | >800 | >900 | >1000 | >800 | >500 | >500 |
| Density | g/cm3 | 0.96-0.98 | 0.96-0.98 | 0.96-0.98 | 0.96-0.98 | 0.96-0.98 | 1.02-1.35 |
| Packing numbers | PCS/m3 | >630000 | >830000 | >850000 | >260000 | >97000 | >97000 |
| Porosity | % | >85 | >85 | >85 | >85 | >90 | >90 |
| Dosing ratio | % | 15-67 | 15-68 | 15-80 | 15-67 | 15-65 | 15-65 |
| Membrane-forming time | Days | 3-15 | 3-15 | 3-15 | 3-15 | 3-15 | 3-15 |
| Nitrfication efficiency | GNH4-N/m3. D | 400-1200 | 400-1200 | 400-1200 | 400-1200 | 400-1200 | 400-1200 |
| BOD5 oxidation efficiency | GBOD/m3. D | 2000-10000 | 2000-10000 | 2000-10000 | 2000-10000 | 2000-10000 | 2000-10000 |
| COD oxidation efficiency | GCOD/m3. D | 2000-15000 | 2000-15000 | 2000-15000 | 2000-15000 | 2000-15000 | 2000-15000 |
| Applicable temperature | ºC | 5-60 | 5-60 | 5-60 | 5-60 | 5-60 | 5-60 |
| Life-span | Year | >15 | >15 | >15 | >15 | >15 | >15 |
| Model | | PE07 | PE08 | PE09 | PE10 |
| Spec | mm | Φ35*18 | Φ5*10 | Φ15*15 | Φ25*4 |
| Hole Numbers | PCS | 19 | 7 | 40 | 64 |
| Efficient surface | M2/m3 | >350 | >3500 | >900 | 1200 |
| Density | g/cm3 | 0.96-0.98 | 1.02-1.05 | 0.96-0.98 | 0.96-0.98 |
| Packing numbers | PCS/m3 | >33000 | >2000000 | >230000 | >210000 |
| Porosity | % | >92 | >80 | >85 | >85 |
| Dosing ratio | % | 15-50 | 15-70 | 15-65 | 15-65 |
| Membrane-forming time | Days | 3-15 | 3-15 | 3-15 | 3-15 |
| Nitrfication efficiency | GNH4-N/m3. D | 300-800 | 500-1400 | 500-1400 | 500-1400 |
| BOD5 oxidation efficiency | GBOD/m3. D | 1000-5000 | 2500-15000 | 2500-15000 | 2500-20000 |
| COD oxidation efficiency | GCOD/m3. D | 1000-10000 | 2500-20000 | 2500-20000 | 2500-25000 |
| Applicable temperature | ºC | 5-60 | 5-60 | 5-60 | 5-60 |
| Life-span | Year | >15 | >15 | >15 | >15
|
Bio Filter MBBR Media Main Features:
1. Scientific formula, rapid forming biofilm
Addition of a variety of trace elements in the carriers, improve
its hydrophilic performance,
accelerate growth of microorganism and improve its physiological
activity, rapidly attachment
on the surface of the carriers, and the rapid growth, accelerate
forming membrane and
improve water treatment efficiency.
2. Large specific surface area, attachment more microorganism
Fluid design geometry and special surface treatment, forming a huge
surface area for the
bacteria to create a safe, comfortable living environment, provides
adequate space and
extended conditions.
3. Easy fluidization, low energy consumption
Suitable density , the carriers are more easy fluidization, save
energy consumption. Unique
zigzag structure of carriers, that favor of freely
three-dimensional flow in water, constantly
shock and cutting bubbles in water, increase and oxygen contact
frequency, to provide more
oxygen to the bacteria, fast degradation of organic pollutants in
wastewater.
Advantage
1. Rapid carrier bio film formation mechanism
2. Super decarburization, ammonia nitrogen removal capacity
3. Long service life
4. 100% virgin HDPE material.
