Aquaculture Membrane Aeration Diffuser In Contact Aerator Pool
Product Description
In practical projects, when fine bubble diffuser working, we find
that the region of the highest
stress is mainly in the outer edges and central membrane. As a
result, the stretching of
membrane with traditional design is limited, the membrane is in a
high stress state for some
time, it is very fragile and easy tear, furthermore faces high
aeration resistance.Under such
condition, the oxygenation capacity decreases, the power
consumption and maintenance cost
increase.
In order to avoid the abovementioned defects, we thicken the outer
edges and central
membrane.Unique designs can greatly improve the service life of
YULONG® fine bubble
diffuser.
Finds Application In :
1. Aeration for SBR reaction basin, contact oxidation pond, and
activated sludge aeration
basin in sewage disposal plant;
2. Aeration for denitrification / dephosphorization aerobic
processes;
3. Aeration for excreta and animal wastewater treatment plant;
4. Aeration of deep aeration basin;
5. Aeration for high concentration wastewater aeration basin, and
aeration for regulating pond
of wastewater treatment plant;
6. Aeration of fishpond and other applications.
Features
1.Simple structure, ease of installation
2.Tight sealing without air leakage
3.Maintenance-free design, long service life
4.Corrosion resistance and anti-clogging
5.High oxygen transfer efficiency
Technical Parameters
| Model | HLBQ170 | HLBQ215 | HLBQ260 | HLBQ350 | |
| Bubble Type | Coarse bubble | Fine bubble | Fine bubble | Fine bubble | |
| Size | 6 inch | 8 inch | 9 inch | 12 inch | |
| MOC | EPDM/Silicon membrane
ABS/PP carrier plate | EPDM/Silicon membrane
ABS/PP carrier plate | EPDM/Silicon membrane
ABS/PP carrier plate | EPDM/Silicon membrane
ABS/PP carrier plate | |
| Connector | 3/4'' NPT male thread | 3/4'' NPT male thread | 3/4'' NPT male thread | 3/4'' NPT male thread | |
| Bubble Size | 4-5mm | 1-2mm | 1-2mm | 1-2mm | |
| Design Flow | 1-5m3/h | 1.5-2.5m3/h | 3-4m3/h | 5-6m3/h | |
| Flow Range | 6-9m3/h | 1-6m3/h | 1-8m3/h | 1-12m3/h | |
| SOTE | ≥10%(6m submerged) | ≥38%(6m submerged) | ≥38%(6m submerged) | ≥38%(6m submerged) | |
| SOTR | ≥0.21kg O2/h | ≥0.31kg O2/h | ≥0.42kg O2/h | ≥0.75kg O2/h | |
| SAE | ≥7.5kg O2/kw.h | ≥8.9kg O2/kw.h | ≥8.9kg O2/kw.h | ≥8.9kg O2/kw.h | |
| Headloss | 2000-3000Pa | 2000-4500Pa | 2000-4300Pa | 2000-4200Pa | |
| Service Area | 0.5-0.8m2 | 0.2-0.64m2 | 0.25-1.0m2 | 0.4-1.5m2 | |
| Service Life | >5year | >5year | >5year | >5year |
